The production line can continuously produce corrugated pipes such as PE, PP, EVA, PVC, etc., and can also produce PA bellows. The plastic single-wall corrugated pipe has the characteristics of high temperature resistance, corrosion resistance, wear resistance, high strength and good flexibility. Widely used in automotive wire harnesses, electrical threading, machine tool lines, sheathed tubes for lighting lines, air conditioners, water pipes for washing machines, etc.
The SJDBGZ series plastic single-wall corrugated pipe production line carefully developed by our company passes the gear transmission module, the template is water cooled, and the product is air-cooled, which makes the bellows production speed, uniform corrugation shape, uniform seam, smooth inner and outer walls, especially Harness for high-end cars.
The main technical parameters
| Production pipe range mm | 4.5-9 | 9-32 | 32-50 |
| Host model | SJ-30 | SJ-45 | SJ-65 |
| Host length to diameter ratio L/D | 30:1 | 28:1 | 30:1 |
| Production capacity kg/h | 10 | 40 | 80 |
| Host power kw | 4 | 11 | 18.5 |
| Molding machine power kw | 1.1 | 1.5 | 1.5 |
| Module logarithm | 42 | 38 | 38 |
| Cooling method | water cooling, air cooling | ||
| Production speed m/min | 6-10 | 8-12 | 8-15 |
| Counting method | Count | ||
| Coiler form Maneuvering | manual | ||
